Lionik NiMH/NiCd Consumable & Industrial Charger:

Picture	Type	Nominal Output Volt	Siutable Battery	Dimension
	LKNC0861	DC2.8V	AA/AAA:90~120mA x 2	98 x 38 x 53 mm
	LKNC0862	DC2.4/4.8V	AA/AAA:100mA x 2	99 x 50 x 42 mm
	LKNC0863	DC2.8V	AA/AAA:90~120mA x 4 or 2	115 x 70 x 30 mm
	LKNC0828	DC2.8V	AA:90~120mA x 4	118 x 75 x 45 mm

LKNC0866	DC2.4/4.8V	9V/15mA x 1	96 x 48 x 32 mm
LKNC0866	DC2.4/4.8V	AA/AAA:100mA x 2	96 x 48 x 32 mm
LKNC0868	DC2.8V	AA:120mA x 2 or 4	126 x 80 x 50 mm
LKNC0898	DC1.2V	AA:1600mA x 4	105 x 66 x 30 mm
LKNC0998	DC2.8V	AA/AAA:1A x 2 or 4	105 x 66 x 30 mm

LKNC0550	DC12V	AA/AAA:500mA x 1~4	118 x 75 x 36 mm
LKNC0555	DC12V	AA/AAA:500mA x 1~4	118 x 76 x 30 mm
LKNC0103	DC2.8V	AA/AAA:1A x1~4	160 x 94 x 35 mm
LKNC1506	DC3.6V	AA/AAA:700mA x 1~4	118 x 75 x 36 mm

LKNC0512	DC6V	AA/AAA:1.0A	118 x 75 x 36 mm
LKNC1520	DC7.2V	AA/AAA:1.2A	117 x 61 x 36 mm
LKNC1516	DC 8.4V	AA/AAA:1.3A	117 x 61 x 36 mm
LKNC1512	DC 9.6V	AA/AAA:1.8A	117 x 61 x 36 mm

FEATURES:

Mult types for you select
For world wide use AC input
Charging 2 or 4 NiMH/NiCd Cells
AA/AAA or 9V Cell Can use
2 hours or 4 hours to full
Short circuit protection
Over Charged protection
Over temperature protection circuits
Bad battery detection
Alkaline and primary cell detection
4 independent charging channels
Always plugged-in for Instant energy
Corded type with AC Adapter
Each battery is quick charged in any position
Up to 1000 cycles
High reliability, Fast charge current
Compact size,light weight.
Fully enclosed plastic case
Red/yellow/green LED Display
Approvals:Meeted UL/CE
Great safe,Environmentally friendier

AC Input range
90~264V AC
Fast/Trickle switch
dV/dT=0 or -ΔV>8mV or Timer out or Temperature rise > 8°C
Charging Indicator
Red : Fast Mode Green:Trickle/Finished
Fast Mode Current
1.2C~1/8C (Battery Capacity)
Trickle Mode Current
1/20 ~ 1/50C
Build-in timer setup
1 ~ 10 Hours(option)
Operating temperature
-5°C ~ 40°C
Withstand Voltage
I/P-O/P:3KVAC ,1min.
Safety standards
UL1950,UL1210,EN55022
Humidity
20%~90%
Note: Plug of DC output need be
defined by user
